TSP P4000 Pump

Pump Design: Dual in-line piston, pulseless design. Micro-stepped motor control. Floating piston bayonet-mounted heads. Patented ceramic check valves.

Flow accuracy: ±0.5% at 1 ml/min with water, after liquid end calibration.

Flow precision: <0.2% RSD

Flow Range: 0.01 to 10 ml/min standard. Settable in 0.01 ml/min increments.

Composition Repeatability: 0.2% RSD

Gradient Linearity: ±0.5% from 10-90% composition

Maximum Pressure: 6000 psi, 420 bar, 42MPa with standard heads

Wetted Surfaces: Stainless steel or PEEK, titanium, ceramic, sapphire, Teflon, Tefzel, and polyethylene

Pressure Pulsation: <2% amplitude; <1% typical at 1ml/min water or methanol at >500 psi

Delay Volume: <0.6ml

Compressibility Compensation: Automatic

Shutdown File: Protected in non-volatile memory

Flow Stability Test: Pump flow diagnostic to verify proper pump performance

Diagnostics: Diagnostic tests to verify proper electrical and mechanical operation

Communications: Hardwire external events connector. Run and Stop remote inputs; Ready, Run, Timed Event and Analog Pressure outputs. SCM400 degas communication port.

Ambient Environment: 10-40°C, 5-95% relative humidity, noncondensing.

TSP UV2000 Detector

Wavelength Ranges: D2 lamp: 190 to 365 nm, W lamp: 366 to 800 nm

Lamp: D2 and W standard

Wavelength Accuracy: ± 1.0 nm

Wavelength Precision: <0.01 nm

Bandwidth: 6 nm

Range Selections: 3.0, 2.0, 1.0, 0.5, 0.2, 0.1, 0.05, 0.02, 0.01, 0.005, 0.002, 0.001, 0.0005 AUFS

Absorbance Range: 0.0005 to 3.0 AUFS

Absorance Linearity @ 254 nm: 3.0 AUFS

Analog Outputs: Outputs 1 and 2: Range-selectable over entire absorbance range

Communications:

- Romote Inputs: Run, Stop, and Zero

- Romote Output: Ready

TSP AS3000 Autosampler

Vial capacity:

- 120 vials in three removable trays

- 105 vials with tray temperature control

Variable-Volume:

- Injection Precision: <0.5 % RSD @ 10 pL or greater

- Injection Volume: 0.1 – 100 pL injection standard (250 uL syringe) up to 1000 uL injections with larger loops and syringes

Fixed-Loop:

- Injection Precision: <0.5% RSD @ 10 uL or greater

- Injection Volume: 20 uL standard (250 uL syringe) 1000 uL injections with larger loops and syringes

Sample Carryover:

- <0.0 I% at 300 gL flush volume

- 5 mL flush volumes can be set

Minimum Sample Volume: 1 uL can be injected from 5 uL with an end-port needle

Needle Height: Programmable in 0.1 mm increments

Method Files: Protected in non-volatile memory

Communications

- Pump Ready, Inject Hold

- Outputs Pump Stop, Autosampler Ready, Inject, Gradient Start, Four timed-event outputs

- SpectraNETIRS-232 port

Ambient Environment: 10° – 40°C, 5 – 95% relative humidity

Dimensions: 37cm x 41 cmx 51 cm (HxWxD)
