TSP UV2000 Detector

Wavelength Ranges: D2 lamp: 190 to 365 nm, W lamp: 366 to 800 nm

Lamp: D2 and W standard

Wavelength Accuracy: ± 1.0 nm

Wavelength Precision: <0.01 nm

Bandwidth: 6 nm

Range Selections: 3.0, 2.0, 1.0, 0.5, 0.2, 0.1, 0.05, 0.02, 0.01, 0.005, 0.002, 0.001, 0.0005 AUFS

Absorbance Range: 0.0005 to 3.0 AUFS

Absorance Linearity @ 254 nm: 3.0 AUFS

Analog Outputs: Outputs 1 and 2: Range-selectable over entire absorbance range

Communications:

- Romote Inputs: Run, Stop, and Zero

- Romote Output: Ready

TSP AS3000 Autosampler

Vial capacity:

- 120 vials in three removable trays

- 105 vials with tray temperature control

Variable-Volume:

- Injection Precision: <0.5 % RSD @ 10 pL or greater

- Injection Volume: 0.1 – 100 pL injection standard (250 uL syringe) up to 1000 uL injections with larger loops and syringes

Fixed-Loop:

- Injection Precision: <0.5% RSD @ 10 uL or greater

- Injection Volume: 20 uL standard (250 uL syringe) 1000 uL injections with larger loops and syringes

Sample Carryover:

- <0.0 I% at 300 gL flush volume

- 5 mL flush volumes can be set

Minimum Sample Volume: 1 uL can be injected from 5 uL with an end-port needle

Needle Height: Programmable in 0.1 mm increments

Method Files: Protected in non-volatile memory

Communications

- Remote Inputs: Pump Ready, Inject Hold

- Outputs Pump Stop, Autosampler Ready, Inject, Gradient Start, Four timed-event outputs

- SpectraNETIRS-232 port

Ambient Environment: 10° – 40°C, 5 – 95% relative humidity

Dimensions: 37cm x 41 cmx 51 cm (HxWxD)
